Motorcycle Test Bench Tuning Custom Mapping

Retune the injection system, create a new mapping, chip tuning but how?

a) A permanently installed additional module
The advantage: The original periphery remains untouched. As soon as the module is removed again, the original condition is reached again. The disadvantage: The costs of the additional equipment, as well as its installation, are higher.

b) Direct access to the original control unit.
The advantage: The possibilities for modifications are usually greater. Additional devices like exhaust flaps, lambda probe, secondary air system, etc. can usually be deactivated. The disadvantage: To return to the original state, the ECU must be reprogrammed (reset) again.

Individual tuning
For individual map creation, the mixture composition is measured by means of a lambda probe in the exhaust and corrected to the optimum values. This is usually done every 250 rpm, as well as at the various throttle positions 2, 5, 10, 20, 40, 60, 80 and 100%. The power gain is usually 5-15 hp in the top-end power and up to 20 hp in the lower and middle throttle and rpm ranges, depending on how well or poorly the original map was designed.
